KPO TX-101A

SWR/Power Meter 1,6-60 MHz | Max. 2 kW


Description
Excl VAT
Incl VAT
Per
Qty

KPO TX-101A
Art. 30415272
In stock. Delivered in 2-5 working days
Excl VAT € 131,41
incl VAT € 131,41
Per 1 St.
All prices excl. shipping costs
FOR EU PRIVATE CUSTOMERS
VAT will be automatically recalculated for the country, of which the flag on top has been chosen.

COMPANIES WITH EU VAT-ID-NUMBER
Please register with EU VAT-ID-No. before ordering online the first time. After manual check we will change VAT into 0%. Existing customer, please login first.
Recommend item to a friend
Download this info in PDF
Download manual

YouTube geblokkeerd

To view YouTube videos you must accept the 'Marketing' cookies.

The KPO TX-101A is a high quality SWR/Power meter for accurate measuring of forward power, reflected power and SWR on HF frequencies. The meter has an active PEP function and a display with backlight.

Specifications

Frequency range : 1,8-60 MHz
Type meter : Cross Needle
Technical construction : SMD
Power handling : 20 W - 200 W - 2 kW
Min. power input SWR : 1 W
Precision : Low ± 10% (AVG); ± 15% (PEP)
 : High ± 5% (AVG); ± 10% (PEP)
Impedance : 50 Ohm
Voltage : 9-14 VDC 200 mA max. (DC cable is included)
I/O connectors : 2 x PL-female (SO 239)
Dimensions : W184 x H118 x D131 mm
Weight : 0,9 kg

Dimensions and weight are including packaging
Dimensions  :  L19,5 x B14,5 x H13 cm
Weight  :  2,00 kg
